ThermalMAX
The ThermalMAX Roof Hatch sets the new standard for thermally efficient roof hatches. Designed with a thermal break to keep cool-cool and hot-hot, this hatch boasts an R-20 insulation rating making it today's most energy efficient hatch.
FEATURES
- IECC Compliance
- Enhanced Insulation
- Thermal Break
MATERIAL
-
Aluminum: 11 gauge, mill or powder coat
SIZE
- Min: 26" x 24"
- MAx: 48" x 120"
COVER Thermally broken formed metal cover with liner, stiffened to withstand a live load of 40 psf with a max deflection of 1/150 of the span
CURB Thermally broken single wall curb with EZ tab counterflash and mounting flange
INSULATION 3 inch single layer foil-faced polyiso in curb and cover; R-20.3
Specifications
| Model | BRHT |
| Material | 11 gauge Aluminum |
| Finish | Mill |
| Cover | Formed metal cover withstands a live load of 40psf with a max deflection of 1/150 the span |
| Curb | Single wall curb with railing ready EZ tab counterflash and mounting flange |
| Insulation | 3 inch polyiso in curb and cover; R-20.3 |
| Gasket | Extruded EPDM adhesive backed acoustic gasket seal, continuous around curb and cover to assure a continuous seal |
| Spring | Gas spring with integrated damper for smooth, controlled lift assistance |
| Hold Open Arm | Zinc plated steel automatic hold open arm locks cover in open position |
| Hinge | Heavy-duty pintle hinge with stainless steel hinge pin |
| Latch | Zinc plated steel spring-type slam latch with inside and outside operating turn handles and padlock hasp provisions; 20psf wind uplift |
| Pull Handle | Interior safety pull down handle, yellow powder coat |
| Warranty | Five (5) years |
